ER Camera Series

Extended Range Cameras

PV75 785/1000HD-SDI IR 800/1600HD EO

Monitor
Track
Automate
Remote Power Cycle
Single Enclosure

MULTI-PURPOSE
WEATHER HARDENED
INFRARED & ELECTRO OPTICAL

HD MWIR Camera Options:

  • 600 mm mid-wave infrared (3-5µm) HD-SDI with 14.6 to 1.2 degree FOV, 20,000 hr HOT sensor

    OR

  • 785 mm mid-wave infrared (3-5µm) HD-SDI with 16.6 to 0.9 degree FOV, 20,000 hr HOT sensor

    OR

  • 1000 mm mid-wave infrared (3-5µm) HD-SDI with 10.5 to 0.7 degree FOV, 20,000 hr HOT sensor

HD Electro Optical Camera Options:

  • 800 HD-IP electro optical sensor with 21 - 800mm focal length 40x optical zoom including ICR cut filter for near infrared capability

    OR

  • 1600 HD-IP electro optical sensor with 1600mm focal length 40x optical zoom including ICR cut filter for near infrared capability

This series includes:

  • Continuous 360° pan 180° tilt

  • Modular components, ruggedized custom casing for ease of transport

  • ARCA rail optics install for fast, secure, repeatable setup and quick release

  • Master plate allows flexible and optional configuration

  • Local, remote, autonomous C2

  • Gamepad and mouse controllable

  • API

Mil spec connectors (38999) provide environmentally protected connections for a multitude of environments. Additional cabling and mounting brackets available.

Download Datasheet
